Pneumatic Cross Shaft Power Press

Name: Pneumatic Cross Shaft Power Press
Brand: MAX POWER ENGINEERS
Price: 1480000.0 INR
Availability: InStock

Price 1480000.0 INR/ Ton

Get a Price/Quote

MOQ : 1 Ton

Pneumatic Cross Shaft Power Press Specification

Usage
Industrial

Material
Mild Steel

Power
63 Ton

Voltage
380 - 440 Volt (v)

Dimension (L*W*H)
1300 x 900 x 2300 mm

Application
Sheet Metal Stamping, Blanking, Forming

Accessories
Electric Control Panel, Pneumatic System, Safety Guard

Slide Area
400 x 350 mm

Throat Depth
300 mm

Type
Pneumatic Cross Shaft Power Press

Bed Size
900 x 500 mm

Automation Grade
Semi-Automatic

Number of Strokes per Minute
50-60 SPM

Max Stroke Length
120 mm

Shut Height
350 mm

Ram Adjustment
80 mm

Control
PLC or Relay Type

Frame Type
C-Frame

Pneumatic Cross Shaft Power Press About

We Are Leading Manufactures And Exporter Of Cross Shaft Power Press ,Mechanical Power Press,Shearing And Bending Machine And All Types Of Sheet Metal Machinery In Rajkot,Gujarat,India

Precision and Efficiency for Industrial Metal Forming

Engineered for demanding environments, the Pneumatic Cross Shaft Power Press excels in various sheet metal operations. With its 63-ton power capacity and adaptable bed, it is ideal for stamping, blanking, and forming. Integral safety guards and a reliable pneumatic system ensure smooth, controlled, and secure operation. Its semi-automatic mode balances operator involvement with automation, supported by either PLC or relay controls for flexibility.

Versatile, Durable, and Operator-Friendly Design

Constructed from mild steel and framed in a stable C-Frame design, this power press resists deformation during heavy-duty use. Adjustable stroke length and ram settings enable different job requirements, while the slide and shut height dimensions allow for varied workpiece sizes. The electric control panel and safety mechanisms promote both user safety and machine longevity in high-throughput manufacturing environments.

FAQ's of Pneumatic Cross Shaft Power Press:

Q: How does the Pneumatic Cross Shaft Power Press operate in an industrial setting?

A: This power press utilizes a pneumatic system, controlled by PLC or relay mechanisms, to drive the ram with precision for stamping, blanking, or forming sheet metal. Its semi-automatic operation lets operators easily manage the process while ensuring consistency and efficiency across production cycles.

Q: What materials and thicknesses can this power press handle?

A: Designed for use with a wide range of metal sheets, the mild steel build and 63-ton capacity allow it to efficiently process various metals, depending on the thickness and formability required in applications like stamping and forming.

Q: When should I consider using this power press over mechanical alternatives?

A: Choose the Pneumatic Cross Shaft Power Press when you need smoother, controlled operations with fewer vibrations, especially for precision sheet metal work, moderate-to-high production volumes, or when automation via pneumatic and PLC/relay control is beneficial.

Q: Where is this power press most commonly installed?

A: This equipment is ideal for installation in manufacturing plants, fabrication shops, and industrial units focusing on sheet metal component production or custom metal stamping projects across India.

Q: What is the step-by-step process for operating the power press safely?

A: Operators must first adjust the ram and stroke settings for the job specifications, secure the workpiece on the bed, and select the desired control mode (PLC or relay). Protective guards should be checked before cycling the press. The operation is then activated, with safety mechanisms ensuring safe, reliable stamping throughout.

Q: How does the semi-automatic mode benefit production?

A: Semi-automatic operation streamlines repetitive tasks without requiring full manual intervention for every stroke, thus increasing throughput, reducing operator fatigue, and maintaining accuracy, while still allowing for necessary monitoring and intervention.
